SALES INFORMATIONS
| Price unit | 1 |
| Packing unit | 1 |
| unit | PC |
| minimum order quantity | 1 |
Technical data
| Area of application (material to be processed): | Universal, P, M, K |
| Relative length: | short |
| Material: | HSS-Co |
| [A1] Cutting diameter mm: | 2 |
| [A5] Neck diameter mm: | 0.00 |
| Coating [H5/COATN]: | uncoated |
| [B2/B6] Cutting length max. mm: | 4.00 |
| Manufacturer item number shop: | 160821 2,00 |
| Cutter type: | Type N |
| Center cut: | Yes |
| [B3] Collar length mm: | 0.00 |
| Helix angle: | 30 ° |
| [G5] Profile angle: | 90 |
| [B3/B4/B5] Total length mm: | 35 |
| [C12] Recording form, machine side: | 1835 B-stock |
| [C3] Mounting diameter, machine side mm: | 6 |
| [F21] Number of effective cutting edges, circumferential: | 3 |
